SPECIFICATION

• SPECIFICATIONS
• RATING : 16A, 26A 250/125VAC.
• CONTACT RESISTANCE : 50mΩ max.@1A 12VDC (initial value)
• INSULATION RESISTANCE : 100mΩ min. at 500VDC
• DIELECTRIC STRENGTH :1,500V RMS @ sea level
• OPERATION TEMPERATURE : -25°C to 85°C
• MECHANICAL LIFE : Momentary 1,000,000 cycles
• Latching 500,000 cycles
• ELECTRICAL LIFE : 16A /125&250VAC 50,000 CYCLES
• 26A /125&250VAC 10,000 CYCLES
• OPERATION PRESSURE : 3.5±1.5N
• TRAVEL : About 3.2mm
• INGRESS PROTECTION : IP67, IK08(Stainless)
• TORQUE: 1~3Nm

MATERIALS

• MATERIALS
• BUSHING : Stainless Steel / Aluminum alloy
• BASE : PBT(UL 94-V0) , PC(UL 94-V2)
• ACTUATOR : PC ; Stainless Steel / Aluminum alloy
• INNER ASSEMBLY : POM / PA66.
• SPRING : Steel.
• SEALING : Sillicone.
• O-Ring : Sillicone.
• TERMINAL: Brass ,Silver plated.
• HEX NUT : Nickel plated brass.
