CONTACT MATERIAL OPTIONS
Silver&Gold over Silver
3 Amps with resistant load＠120VAC or 28VDC
1 Amps with resistant load＠250VAC
Gold：0.4 Volt-Amps(VA)max. @ 20V max. (AC or DC)

SOLDERING PROCESSES
WAVE SOLDERING : Recommended Soldering Temperature:260150C
Duration of Solder Immersion: 5 11 seconds
(PCB is 1.6mm in thickness)
SOLDERING : Vapor phase
